POS AV

Engineered for aerial cameras, scanning lasers, imaging sensors, synthetic aperture radar, and LIDAR technology.

POSAV

POS AV is a hardware and software system specifically designed for Direct Georeferencing of airborne sensor data. By integrating precision GNSS with inertial technology, POS AV enables geospatial projects to be completed more efficiently, effectively, and economically. Supported by Applanix' industry expertise and technological innovation, POS AV is engineered for aerial cameras, scanning lasers, imaging sensors, synthetic aperture radar, and LIDAR technology.

The POS products are available to OEMs and systems integrators in the form of a Trimble AP GNSS-Inertial Board Set plus Inertial Measurement Unit (IMU).

The POS AVX 210 is the latest addition to our POS AV product portfolio. The POS AVX 210 enables airborne surveyors to achieve gains in accuracy, efficiency and productivity for low-altitude or small form factor sensors, when compared to GNSS-only point-matching or aerial triangulation techniques.

POSPac Mobile Mapping Suite is Applanix' next generation, industry-leading software for Direct Georeferencing of mobile mapping sensors using GNSS and inertial technology. Learn more.

ARTICLES AND PAPERS »

CASE STUDIES »

RELATED PRODUCTS »

Compact, low-power, lightweight, rugged construction
High-performance, survey-grade multi-frequency GNSS receiver
Full in-air alignment support
Embedded Omnistar SBAS correction service
High-performance, low profile FAA certified GNSS-L Band antenna

POSPac MMS post-processing software bundle includes Carrier Phase DGPS processing, Integrated Inertial/GNSS processing, and optional photogrammetry tools for EO generation, IMU boresight calibration and quality control
Commercial grade IMUs for ease of export
Real-time leveling and yaw drift correction of stabilized mounts
Internal data logging for redundancy
Meets airborne environmental operational requirements

Trimble CenterPoint™ RTX™ correction service available
Simple to use and operate with auto-log and auto-start functions
Removable USB data logging with unique sealed port
Multiple interfaces for simple integration with imaging sensors

Provides an accurate real-time and post-mission solution for all motion variables including sensor-specific Exterior Orientation (EO) parameters using Direct Georeferencing
Allows for single stereo model mapping and single photo orthorectification using an existing Digital Elevation Model

Streamlines and automates the data workflow and quality control processes
Easily integrated with digital cameras, film cameras, LIDAR systems, SAR systems, and digital scanners
Ideally suited to inhospitable environments and rapid response applications where ground control is not available

Eliminates the requirement for aerotriangulation and a complete ground control survey (often only check points for quality control are needed)
Improves productivity in traditional aerial mapping applications, which translates into operational time and costs savings, with increased accuracy

"Choosing Applanix was that simple, Applanix is the leader in the field and it was important to us to put their equipment in our aircraft and also to marry it with all the sensors systems so we could carry several payloads and that way we will be able to leapfrog some of the existing fixed wing aircrafts that fly Applanix systems. So we are very keen to keep working with Applanix on future developments."

Dr. Brian Eggleston, Brican Flight Systems Inc

“Applanix products are extremely reliable. We push them hard and they stand up. Their customer service is also exceptional – extremely high expertise and very quick response”

Ezra Philipse, Technical Director, Aerodata International
