The M600/YellowScan VX-20 with Trimble APX-20 UAV for Direct Georeferencing is ideal for fast and safe landslide detection.
L’Avion Jaune is an expert in drone design, airborne data acquisition and processing. The company has been at the forefront of environmental survey in France, pioneering the use of fully Direct Georeferenced UAV LiDAR to map geohazards. The M600/VX-20 offers high-precision, cost-effective and efficient aerial mapping.
The natural degradation of limestone cliffs generates landslides and falling debris, threatening the land, roads and people beneath.
Without the ability to map and accurately assess the stability of these land formations, the management of this risk currently relies primarily on trajectory analysis. This consists of simulating falling rock masses from ridges to the valley floor, using calculations that consider the size, energy and shape of the material. While this allows for some risk assessment, detailed and correct maps based on high-resolution UAV LiDAR DTM, and integrity analysis is required for complete risk analysis.
The configuration and the hazardous nature of the terrain do not allow for crews to operate traditional survey equipment on the ground. Using a UAV LiDAR system enables: rapid generation of cost-effective, accurate DTM and 3D products, safe operation, ability to access unreachable areas, and perform repeat monitoring.
As a result, L’Avion Jaune used the Multirotor M600 equipped with the YellowScan VX-20 and Applanix APX-20 UAV. It was deployed to evaluate landslide activity using LiDAR.
Mission parameters included the following:
Mission and acquisition:
Four flights of fifteen minutes each were required to map the entire project area. This operation was carried out at sunrise when the road had little traffic. Checkpoints were then surveyed with differential GPS. The data processing involved computation of georeferenced trajectory, matching flight lines, and point cloud classification took about two days.
This allowed L’Avion Jaune to optimize the choice of material and work with best practices to collect and process LiDAR data required for high-accuracy mapping in dense vegetation. The flexible UAV deployment of resources allowed the acquisition of dense point clouds (100 pts / m²) and the generation of a precise and exhaustive DTM in under three days.
This collaboration of L’Avion Jaune, YellowScan, and Applanix, will allow for the implementation of safety and prevention plans for the protection of traffic, pedestrians, infrastructure, and wildlife.
“The generation of a 3D model of cliffs, overhanging a frequented road was essential for the safety of traffic and people below. The site footprint modelled by the YellowScan VX-20 with Applanix DG inside was 200m high, 300 m wide and 2.5 km long, to a high-precision without exposing crews to danger,” says Benjamin Pradel, Aerial Survey Project Manager, L’Avion Jaune.
